EWI-090 Monocouche Render

The EWI-090 Monocouche Render is a high-performance cement-based, through-coloured scratch render. This decorative render has been designed with water-repellence, breathability, and durability in mind. The EWI-090 is used on both larger commercial or residential projects, and suitable for concrete, clay, block, and brick substrates. Monocouche Scratch Render is a thick coat render that is applied in two passes. The material base is comprised of premium quality Portland cement, hydrated lime, polymers and modifying admixtures. This delivers enhanced adhesive properties, ensuring a flexible and crack-resistant finish is achieved. The EWI-090 is a low maintenance product that achieves a natural stone-like appearance for a long-lasting decorative finish.

Preparation

All surfaces should be clean, dry and free from material that may impair application. Prime the substrate before application. We recommend the EWI-310 Universal Primer. The EWI-090 Monocouche Render is a dry mixture, mix with clean, potable water to activate the ingredients. Pour the 25kg dry mix bag into approx. 4.5-5 litres of water. Mix thoroughly for 2 minutes, leave to stand, and then re-mix.

Monocouche Render Application

Apply render to the primed surface in two passes. Apply the first pass with a stainless steel trowel or spray pump at a thickness of 10mm and embed fibreglass mesh in the first pass. Then, apply the second pass to a thickness of 8-9mm, then scratch it back to 2-3mm to give the completed finish. The total depth will be between 15-17mm. Drying time varies depending on weather conditions. Note: Avoid rendering below the DPC or within 150mm of ground level.

Coverage Rates

1 bag of Monocouche render covers 1m²

Technical Specification

• Setting temperature:+5°C to +25°C
• Bulk density: 1650 kg/m³
• Reaction to fire: A
• Thermal conductivity: (λ10, dry) 0.82 W/mK (tab. mean value; P = 50%)
• Adhesion: ≥ 2.0 N/mm2 (FP) B

Storage Conditions

Store unopened, in original packaging, and in a cool, dry place. Shelf life: 12 months from date of manufacture. *Packaging may differ slightly to the product image
