The 8mm Hammer Fixing with Metal Pin & Short Expansion Zone is a hammer-driven fixing designed for securing external wall insulation (EWI) systems. Featuring a durable polyethylene body and a steel pin with plastic-sealed head, it provides strong anchorage while reducing point thermal conductivity. The short expansion zone enables efficient fixing into solid substrates, with a secure flush finish thanks to its innovative telescopic sleeve design. Suitable for EPS and Mineral Wool insulation, this fixing offers fast installation and long-term stability in ETICS applications.

Suitable Insulation Boards

Compatible Substrates (ETA Categories A–C)

If the substrate condition is uncertain, carry out a pull-out test to confirm suitability.

Key Features

• Steel pin with plastic-sealed head reduces thermal transfer and resists corrosion.
• Short expansion zone provides secure anchorage in dense substrates.
• Telescopic sleeve sits flush with insulation for reduced thermal bridging.
• Fast hammer-in installation — ideal for larger façade areas.
• Compatible with EPS & Mineral Wool systems (support washers required for MW).
• ETA-13/0107 approved for EWI systems.

Sizes & Box Quantities

Select length based on insulation thickness + adhesive layer + required embedment depth.

Application

Preparation

• Mark out the fixing grid according to design and wind-load requirements.
• Check for services (cables and pipes) before drilling.
• Use rotary-only mode for hollow blocks; hammer mode for dense substrates.

Installation steps

1. Apply adhesive to insulation boards and place boards tightly with staggered joints.
2. Drill perpendicular through the insulation into the substrate.
3. Insert the fixing body and hammer the metal pin to seat it flush.
4. Do not over-drive or deform the insulation surface.
5. Install fixings per the specified pattern, adding extra around corners and openings.
6. Proceed with basecoat and reinforcement mesh as per system design.

Fixing pattern & density

• Typical density: 4–6 fixings per m², increasing in edge and high-load areas.
• Keep consistent spacing and avoid placing fixings too close to board edges unless specified.

Quality checks

• Perform pull-out tests if substrate condition varies.
• Replace any fixing that spins or fails to grip and re-drill as needed.
