Can I Install EWI on a Cavity Wall?

At EWI Store, we receive many enquiries from homeowners who are very interested in installing EWI, however there is often confusion as to whether it is possible to install EWI on a home with existing cavity wall insulation. In today’s post, we’re going to be tackling this question to see if we can clear things up!

What is Cavity Wall Insulation?

If your home was built after the 1920’s, it’s likely that it will have been built with a cavity between the two exterior walls.

The main purpose of this cavity was to prevent damp crossing over from the outside through to the interior walls, but it wasn’t until later that people realised it could be used for another purpose. Nowadays, cavity walls are often filled with an injectable insulation material in order to increase energy efficiency and reduce the amount of heat lost through the walls.

In today’s housing stock, CWI seems to be the default method of wall insulation, however this isn’t to say that there haven’t been people with negative experiences of it. Damp and condensation have often been reported as a side-effect of cavity wall insulation, usually occurring as a result of cold bridges  caused by poor installation. There are therefore many people who are quite rightly wary of cavity wall insulation, so they instead look elsewhere for their wall insulation solutions.

What is External Wall Insulation?

If your home was built before the 1920’s, then it’s likely to be a solid wall property. These properties present a bit of a challenge in terms of increasing energy efficiency because there is no cavity to fill, so homeowners either have to opt for no insulation (and high energy bills), internal wall insulation or external wall insulation.

External wall insulation (EWI) provides the best solution for this type of building, as it is retrofitted onto the outside walls by securing the insulation boards with adhesive and fixings. A protective render is then applied to the insulation boards to create a weatherproof seal.

Unlike internal wall insulation, where the thickness of the insulation is severely limited by how much floor space you can give up, EWI allows users to install insulation as thick as 200mm onto the outside walls of their properties.

Further to this, the effectiveness of cavity wall insulation is dictated by the amount of insulation that can actually fit within the cavity – some cavities are just 50mm wide, so the benefits of insulating this are pretty slim.

EWI therefore offers an increased potential for homes to massively up their efficiency. Unfortunately, it’s commonly assumed that homes with cavity wall insulation are a) insulated well enough and b) cannot have EWI as well as CWI.

Can I have both EWI and CWI?

In fact, if you have cavity wall insulation, then EWI is likely to reduce any problems with damp caused by the cavity wall insulation. This is because external wall insulation completely envelopes your home in a weather-proof blanket, preventing water from entering through the exterior walls and keeping the temperature of the walls nice and warm. Because EWI wraps around the entirety of the exterior walls, there are no gaps and therefore thermal bridging is kept to a minimum.

So because the internal temperature of the walls increases, the chances of damp and interstitial condensation are reduced. If there were any cold spots within the cavity wall insulation before, then the EWI will counteract the effect of these by maintaining a warm wall temperature.

If you currently live in a cavity insulated house and you want to upgrade the wall insulation even further, then get in touch! We can talk you through the process and offer you our technical expertise.
